Quick Connect Fiber Connectors, Optical Fiber Fast Connector Fast Connector: A fast connector is a specialized type of connector that allows users to quickly establish fiber optic connections without the need for special tools or complex procedures. These connectors are especially useful for temporary connections, rapid deployment, and maintenance, particularly in Fiber-to-the-x (FTTx) deployments. SC/APC Fast Connector (CC-FCSA-250PLW), suitable for: 3.0 x 2.0 mm/2.0- 3.0mm Cable, Fiber Diameter: 125μm (652 & 657), Coating Diameter: 250μm, Mode: SM, Insertion Loss: ≤ 0.3dB (1310nm & 1550nm), Return Loss: ≤ -50dB, Tensile Strength: >5 N, Tighten Strength of Coating: >10 N.
Spesifikasyon
|
Atik |
Spesifikasyon |
|
Kab Dimansyon |
3.0 x 2.0 mm/2.0- 3.0mm kab |
|
Dyamèt fib |
125μm (652 & 657) |
|
Dyamèt kouch |
250μm |
|
Mòd |
SM |
|
Tan operasyon |
apeprè 15s (eksepte prereglaj fib) |
|
Pèt Ensèsyon |
Mwens pase oswa egal a 0.3dB (1310nm & 1550nm) |
|
Retounen Pèt |
Mwens pase oswa egal a -50dB |
|
Pousantaj Siksè |
>98% |
|
Tan ki kapab itilize ankò |
>10 fwa |
|
Fòs rupture |
>5 N |
|
Sere boulon fòs nan kouch |
>10 N |
|
Tanperati |
-40-+85 degre |
|
Tès fòs rupture sou entènèt (20 N) |
△ IL Mwens pase oswa egal a 0.3dB |
|
Durabilité mekanik (500 fwa) |
△ IL Mwens pase oswa egal a 0.3dB |
|
Tès gout (4m etaj konkrè, yon fwa chak direksyon, twa fwa total) |
△ IL Mwens pase oswa egal a 0.3dB |
